C1430
VSH XPress C1430 ist ein Übergangsbogen aus C-Stahl mit einer Pressmuffe und einem Außengewinde. Durch die Verwendung von VSH XPress in Ihrer Rohrleitungsinstallation können Sie schnell, einfach und sauber installieren. VSH XPress bietet ein komplettes Rohrleitungssystem, das für jede denkbare Anwendung geeignet ist.
Anwendungen
Einsatzbereich
Zertifikate
Artikelnummer | Abmessung | Gewicht | L x B x H | Verpackung | GTIN |
---|---|---|---|---|---|
6201976 | 12xR3/8" | 0,04 kg | 45x51x17 mm | Beutel (10 stk) | 08711985095579 |
6201987 | 15xR3/8" | 0,06 kg | 52x56x19 mm | Beutel (10 stk) | 08711985095593 |
6201998 | 15xR1/2" | 0,07 kg | 54x61x22 mm | Beutel (10 stk) | 08711985095616 |
6202009 | 18xR1/2" | 0,08 kg | 58x67x22 mm | Beutel (10 stk) | 08711985095630 |
6202011 | 22xR3/4" | 0,16 kg | 68x77x30 mm | Beutel (10 stk) | 08711985095654 |
6202020 | 28xR1" | 0,18 kg | 81x92x36 mm | Beutel (5 stk) | 08711985140644 |
6202031 | 35xR1 1/4" | 0,29 kg | 98x108x46 mm | Beutel (5 stk) | 08711985139372 |
6202042 | 42xR1 1/2" | 0,37 kg | 115x122x50 mm | Beutel (2 stk) | 08711985139389 |
6202053 | 54xR2" | 0,52 kg | 140x148x60 mm | Beutel (2 stk) | 08711985095739 |
Artikelnummer | Abmessung | d1 | DN1 | l1 | z1 | d2 | DN2 | l2 | slw2 | Radius | Winkel |
---|---|---|---|---|---|---|---|---|---|---|---|
6201976 | 12xR3/8" | 12,0 | DN10 | 35 | 18 | 17,2 | 3/8" (DN10) | 42 | 17 | 15 | 90 |
6201987 | 15xR3/8" | 15,0 | DN12 | 41 | 21 | 17,2 | 3/8" (DN10) | 45 | 19 | 18 | 90 |
6201998 | 15xR1/2" | 15,0 | DN12 | 41 | 21 | 21,3 | 1/2" (DN15) | 50 | 22 | 18 | 90 |
6202009 | 18xR1/2" | 18,0 | DN15 | 45 | 25 | 21,3 | 1/2" (DN15) | 54 | 22 | 22 | 90 |
6202011 | 22xR3/4" | 22,0 | DN20 | 51 | 30 | 26,9 | 3/4" (DN20) | 62 | 30 | 27 | 90 |
6202020 | 28xR1" | 28,0 | DN25 | 61 | 38 | 33,7 | 1" (DN25) | 74 | 36 | 34 | 90 |
6202031 | 35xR1 1/4" | 35,0 | DN32 | 72 | 46 | 42,4 | 1 1/4" (DN32) | 86 | 46 | 42 | 90 |
6202042 | 42xR1 1/2" | 42,0 | DN40 | 87 | 57 | 48,3 | 1 1/2" (DN40) | 96 | 50 | 51 | 90 |
6202053 | 54xR2" | 54,0 | DN50 | 105 | 70 | 60,3 | 2" (DN50) | 116 | 60 | 65 | 90 |
Farbe | silber |
---|---|
Materialien | Stahl (St 34.2 (1.0034)) |
Verarbeitung | Verzinkt |
Hersteller | Aalberts integrated piping systems B.V. (VSH) |
Formen | Bogen, Reduktion (90º) |
Verbindung | Press (M), R - konisches Aussengewinde (BSPT) |
Abdichtung | EPDM |
Produktgruppe | Fittings |
---|---|
ETIM klasse | EC003024 Fitting mit 2 Anschlüssen |
Intrastat-Nummer | 73079980 |
Herkunfstland | Niederlande |
Marke | VSH |
Serie | XPress C-Stahl |
Produkttyp | C1430 |
SCIP | 233056dc-cd46-44db-9410-a4845109c0f6 |
ATG3056_XPress_Carbon_F Zertifikaten |
Herunterladen | |
C1430 Bild |
png | Herunterladen |
SDS VSH XPress Carbon Link zum Blatt |
Herunterladen | |
VSH XPress Carbon LPCB Zertifikaten |
Herunterladen | |
VSH XPress Carbon Lloyds Register Zertifikaten |
Herunterladen | |
VSH XPress Carbon SBSC Zertifikaten |
Herunterladen | |
VSH XPress QB Zertifikaten |
Herunterladen | |
VSH XPress UL-ULC Zertifikaten |
Herunterladen | |
VSH _XPress_VdS Zertifikaten |
Herunterladen | |
VSH_SudoXPress_stainless_carbon_BV Zertifikaten |
Herunterladen | |
VSH_XPress_Carbon-SPF Zertifikaten |
Herunterladen | |
VSH_XPress_Galvanized_RINA Zertifikaten |
Herunterladen | |
VSH_XPress_carbon_RISE Zertifikaten |
Herunterladen | |
ATG3056_XPress_Carbon Zertifikaten |
Herunterladen | |
Diagram Diagramm |
png | Herunterladen |
VSH XPress installation instructions Installations- & Wartungsdokument |
Herunterladen |
Eigenschaften | Wert |
---|---|
ETIM klasse | EC003024 Fitting mit 2 Anschlüssen |
Werkstoff des Anschlusses 1 | Stahl |
Werkstoffgüte Anschluss 1 | St 34.2 (1.0034) |
Oberflächenschutz Anschluss 1 | galvanisch/elektrolytisch verzinkt |
Werkstoff des Anschlusses 2 | Stahl |
Werkstoffgüte Anschluss 2 | St 34.2 (1.0034) |
Oberflächenschutz Anschluss 2 | galvanisch/elektrolytisch verzinkt |
Form | Bogen |
Ausführung | 1-teilig |
Winkel des Bogens | 90° |
Exzentrisch | Nein |
Systemgebunden | Ja |
Wanddicke Anschluss 1 | 1,5mm |
Anschluss 1 | Pressmuffe |
Konturcode Verbindung 1 | M |
Anschluss 2 | Außengewinde konisch BSPT-R (ISO 7-1 / EN 10226-1) |
Hauptfarbe Fitting | grau |
Druckstufe Flansch | PN 16 |
Material Dichtung | Ethylen-Propylen-Dien-Kautschuk (EPDM) |
Mit Stoßnocken | Ja |
Zugfest | Ja |
Mediumtemperatur (Dauerbetrieb) | -35°C - 135°C |
Mediumtemperatur (Dauerbetrieb) (imperial) | -31°F - 275°F |
Max. Arbeitsdruck bei 20 °C | 16bar |
Max. Arbeitsdruck bei 20 °C (imperial) | 232,06psi |
Mit thermischer Isolierung | Nein |
Mit Dichtungsmaterial | Nein |
Verschlossen | Nein |
Verbindungsanzeige | Nein |
Mit Entleerungsventil | Nein |
Mit Entlüfter | Nein |
FM-Prüfung | Nein |
DIN-CERTCO-Zertifikat | Nein |
Mit TÜV-Zulassung | Nein |
DVGW-Siegel für Gas | Nein |
DVGW-Siegel für Wasser | Nein |
Zertifiziert nach NF 545 | Nein |
KIWA-Prüfsiegel | Nein |
Gastec QA Prüfung | Nein |
KOMO-Prüfsiegel | Nein |
Typenzulassung nach BBR/EKS | Nein |
